Instruments

A close up of a device Description automatically generated

Our surface analysis ultrahigh vacuum system with the controller rack. The base of the system is the Omicron MULTIPROBE vacuum chamber that houses a variable-temperature scanning tunneling microscope, an X-ray photoelectron spectroscopy system, low energy electron diffraction optics, a quadrupole mass spectrometer, a sputter ion source, e-beam metal evaporators, as well as gas manifolds.

The MULTIPROBE Compact surface science system from Omicron NanoTechnology. The system can be pumped down to pressures lower than 5x10-11 Torr by different stages of pumps including a rotary pump, a turbo molecular pump, an ion pump, and a titanium sublimation pump. It contains an ion gauge, a sample manipulator with an e-beam heater, and a fast entry load lock.



A picture containing table, cake, plate Description automatically generated



A picture containing sitting, motorcycle, blender, old Description automatically generated

Omicron scanning tunneling microscope (VT STM XA 650). It is equipped with a scanner for needle sensor AFM operation. It operates from 300-650 K with a Z-resolution less than 0.1 nm and a tunneling current range between 1 pA and 300 nA.

Reverse view Omicron 4-grid SPECTALEED optics. It features a thoriated tungsten filament, a beam energy ranging from 0 eV to 1 keV, a focus range of 20-500 eV, and a 45 mm-retraction.

A picture containing ware, chain Description automatically generated

A picture containing old, kitchen, airplane Description automatically generated

Omicron EA 125 U1 hemispherical energy analyzer for XPS studies. It features an energy resolution better than 10 meV (FWHM), multi-element Universal Lens with selectable analysis area and acceptance angle.

Omicron DAR 400 X-ray source for XPS studies. It features a twin anode design with an output power up to 400 W and adjustable anode voltage up to 15 kV.



Omicron ISE 5 cold cathode sputter ion source. It features beam currents in excess of 25-45 mA and a very wide energy range from 300 eV to 5 keV. Used for sample cleaning.

Hiden Analytical quadrupole mass spectrometer (HAL/3F PIC) used for TPD experiments.

A picture containing appliance, monitor, table, microwave Description automatically generated

Agilent 7890B gas chromatograph system used for detecting reaction products in dry reforming of hydrocarbon reactions.



AutoChem II 2920 from Micromeritics used for studies of chemical adsorption and temperature-programmed reactions.

A picture containing sitting, table, computer Description automatically generated

Hiden Analytical HPR 20 used for detecting reaction products in dry reforming of hydrocarbon reactions.

MTI OTF-1200X furnace for catalyst synthesis.
