The Ammonia System Diagram parameter screen in PC and NGCC plants gives an overview of the ammonia CO2 control system. This diagram does not contain any numbers and is strictly for reference:
PC: SET PARAMETERS: CO2 Capture, Transport & Storage: 1. Ammonia System: Ammonia System Diagram
