The Auxiliary Fuel Diagram (PC) or Fuel Diagram (NGCC) result diagram displays the natural gas composition and flow rate information, which is described briefly below. This screen is available for PC and NGCC plants.
PC: GET RESULTS: Fuel: Auxiliary Gas Diagram
The following information is shown:
•Area 1 (upper left):
•Gas Flow Rate: The natural gas flow rate to the turbine.
•Area 2 (lower left):
•Our standard natural gas properties are shown here.
