The FG Recycle & Purification Diagram result screen shows the major flows into and out of the flue gas recycle system:
PC: GET RESULTS: CO2 Control: 2. FG Recycle & Purification: FG Recycle & Purification Diagram
The following values are shown:
•Area 1: Primary Recycle: The primary split occurs after the direct contact cooler. The following results refer to the primary flue gas recycle stream:
•Temperature: This is the temperature of the flue gas.
•Flue Gas Flow: This is the volumetric flow rate of the flue gas.
•Area 2: Secondary Recycle: The secondary split occurs before the spray dryer. The following results refer to the secondary flue gas recycle stream:
•Temperature: This is the temperature of the flue gas.
•Flue Gas Flow: This is the volumetric flow rate of the flue gas.
•Area 3: Combined Recycle Flue Gas:
•Temperature: This is the temperature of the flue gas.
•Flue Gas Flow: This is the volumetric flow rate of the flue gas.
•Fly Ash Flow: This is the flow rate of fly ash in the flue gas.
•Water Fraction: This is the fraction of water in the flue gas.
•Area 4: Direct Contact Cooler:
•4a: In:
•Temperature In: The temperature of the flue gas, to be recycled, entering the direct contact cooler.
•Flue Gas In: The volumetric flow rate of the flue gas, to be recycled, entering the direct contact cooler.
•Fly Ash In: The mass flow rate of fly ash in to the direct contact cooler.
•4b: Out:
•Condensed H2O: The mass flow rate of condensed water leaving the direct contact cooler.
•Sulfur Removed: This is the amount of sulfur removed on the direct contact cooler.
•Area 5: Released to Atmosphere:
•Temperature Out: The temperature of the flue gas being released to the atmosphere.
•Flue Gas Out: The volumetric flow rate of the flue gas being released to the atmosphere.
•Fly Ash Out: The mass flow rate of the fly ash being released to the atmosphere.
•Area 6: Other:
•Condensed H2O: The mass flow rate of condensed water.
•CO2 Product Pressure: This is the target pressure of product CO2 being sent to storage.
•CO2 to Storage: The mass flow rate of CO2 being sent to storage.
