The GE Gasifier Diagram result screen shows the major flows into and out of the GE gasifier unit:
IGCC: GET RESULTS: Gasifier Area: GE: GE Gasifier Diagram
Each result is described briefly below:
•Area 1
•Cold Gas Eff.: This is the ratio of the heat contents calculated at room temperature of the syngas fuel output and the coal fuel input. The higher heating value is used here.
•Area 2: Flows Entering the Gasifier
•Temperature In: This is the temperature of the oxidant stream into the gasifier.
•Oxidant In: This is the mass flow of oxidant into the gasifier.
•Water In: This is additional mass flow of water added to the coal. (Wet coal already contains some water).
•Coal In: This is the mass flow of coal into the gasifier on a wet-basis.
•Area 3: Slag
•Sluice Water: Slag collected can be removed from the gasifier and disposed by sluicing the slag with water.
•Wet Slag: Slag collected is removed from the gasifier. Sluice water may or may not be used to facilitate its transportation. This is the total slag flow rate leaving the gasifier on a wet basis.
•Area 4: Flows Exiting the Gasifier
•Temperature Out: This is the syngas temperature exiting the raw gas quench.
•Pressure Out: This is the approximate pressure of the syngas exiting the raw gas quench.
•Syngas Out: This is the mass flow rate of syngas exiting the gasification but prior to the raw gas quench process.
•Syngas Out: This is the volumetric flow rate of syngas exiting the gasification but prior to the raw gas quench process.
