Chemical Looping Diagram

The Chemical Looping Diagram result screen shows the major flows into and out of the chemical looping CO2 capture system:

IGCC: GET RESULTS: CO2 Capture, Transport & Storage: 1. Chemical Looping: Chemical Looping Diagram

Each result is described briefly below:

•Area 1: Air Flow into Air Reactor

•Air In: Mass flow rate of air into the air reactor.

•Temperature: Temperature of air entering the air reactor.

•Area 2: Depleted Air Flow out of Air Reactor

•Air Out: Mass flow rate of depleted air out of the air reactor.

•Temperature: Temperature of depleted air.

•Area 3: Oxidized Oxygen Carrier

•Oxidized OC: Mass flow rate of oxidized oxygen carrier into the fuel reactor.

•Temperature: Temperature of oxidized oxygen carrier entering the fuel reactor.

•OC Makeup: Mass flow rate of oxygen carrier makeup.

•Area 4: Reduced Oxygen Carrier

•Reduced OC: Mass flow rate of reduced oxygen carrier out of the fuel reactor.

•Temperature: Temperature of reduced oxygen carrier leaving the fuel reactor.

•OC Degradation: Oxygen carrier lost to degradation.

•Area 5: Syngas Flow into the Fuel Reactor

•Syngas In: Mass flow rate of syngas into the fuel reactor.

•Temperature: Temperature of syngas entering the fuel reactor.

•Area 6: Syngas Flow out of the Fuel Reactor

•Flue Gas Out: Mass flow rate of syngas leaving the fuel reactor.

•Temperature: Temperature of syngas leaving the fuel reactor.
