The Water Gas Shift Reactor Diagram result screen shows the major flows into and out of the water gas shift reactor (WGSR):
IGCC: GET RESULTS: CO2 Capture, Transport & Storage: 1. Water Gas Shift Reactor: Water Gas Shift Reactor Diagram
Each result is described briefly below:
•Area 1: Steam
•Steam: This is the flow rate of steam added. The steam reacts with CO to produce H2 and CO2 in the presence of the catalyst in the two reactors.
•Area 2: Syngas In
•Temperature In: Temperature of the syngas entering the high temperature reactor.
•Syngas In: Flow rate of the syngas entering the high temperature reactor.
•Area 3: Syngas Out
•Temperature Out: Temperature of the syngas exiting the final heat exchanger.
•Syngas Out: Flow rate of the syngas exiting the final heat exchanger.
