The Ionic Liquid Diagram result screen shows the major flows into and out of the ionic liquid CO2 capture system:


IGCC: GET RESULTS: CO2 Capture, Transport & Storage: 2. Ionic Liquid CO2 Capture: Ionic Liquid Diagram

Each result is described briefly below:

Area 1: Syngas In

Temperature In: Temperature of the syngas entering the CO2 absorber unit.

Syngas In: Flow rate of the syngas entering the CO2 absorber unit.

Pressure In: Pressure of the syngas entering the CO2 absorber unit.

Area 2: Ionic Liquid

Recirculation: This is the total flow rate of ionic liquid through the system.

Makeup: Flow rate of ionic liquid added to the regenerator.

Area 3: Syngas Out

Temperature Out: Temperature of the syngas exiting the CO2 absorber unit.

Syngas Out: Flow rate of the syngas exiting the CO2 absorber unit.

Pressure Out: Pressure of the syngas exiting the CO2 absorber unit.

Area 4: CO2 Product

CO2 Product: Flow rate of the CO2 product exiting the regenerator.

CO2 Pressure: CO2 product pressure entering the pipeline.
