The Purification Unit Diagram result screen shows the major flows into and out of the cryogenic purification unit (CPU):
IGCC: GET RESULTS: CO2 Capture, Transport & Storage: 2. Purification Unit: Purification Unit Diagram
Each result is described briefly below:
•Area 1:
•Flue Gas In: Flue gas entering the CPU.
•Area 2:
•Water Out: Condensed water leaving the compression and drying unit.
•Area 3:
•Purge Out: Purge out of the CPU.
•Area 4: CO2 Product
•CO2 Product: CO2 product leaving the CPU.
•CO2 Prod. Pressure: CO2 product pressure leaving the CPU.
•CO2 Removal: CPU CO2 capture efficiency.
