Bottom Ash Pond



← Previous | Next →



The Bottom Ash Pond result screen shows the major flows into the bottom ash pond:


PC: GET RESULTS: By-Product Management: Bottom Ash Pond

Each result is described briefly below:

Bottom Ash Pond Inputs

Area 1: Wastewater: This is the total wastewater entering the bottom ash pond. This value is zero when wastewater treatment is configured.

Area 2: Bottom Ash

Wet Bottom Ash: Mass flow rate of bottom ash solids on a wet basis.

Mercury: (contained in Bottom Ash) Mass flow rate of mercury present in the bottom ash solids on a wet basis.

Area 3: Fly Ash

Wet Fly Ash: Mass flow rate of total fly ash solids on a wet basis. This value is zero when the fly ash is disposed in a landfill.

Mercury: (contained in Fly Ash) Mass flow rate of mercury present in the fly ash solids on a wet basis.

Bottom Ash Pond Totals

Area 4: Solids

Wet Total Solids: The sum of the fly ash and bottom ash solids on a wet basis.

Total Mercury: Mass flow rate of mercury present in the combined bottom ash and fly ash solids on a wet basis.

Area 5: Effluent: This is the total effluent leaving the bottom ash pond.
