Flue Gas Treatment

← Previous | Next →

The Flue Gas Treatment result screen is only shown when wet FGD is configured:

PC: GET RESULTS: By-Product Management: Fly Ash Disposal

Each result is described briefly below:

•Above the pond: Flue Gas Treatment Inputs: Solids mixed with sluice water that are collected in the bottom of the boiler and by the particulate removal technologies are transported to the Pond for treatment. The IECM currently provides no additional treatment or consideration of these substances, and therefore simply reports the quantities entering the technology.

•Wet Fly Ash: Mass flow rate of total fly ash solids on a wet basis. This value is zero when the fly ash is disposed in a landfill.

•Mercury: (contained in Fly Ash) Mass flow rate of mercury present in the fly ash solids on a wet basis.

•Wet FGD Solids: Mass flow rate of wet FGD solids.

•Mercury: (contained in Wet FGD Solids) Mass flow rate of mercury present in the Wet FGD solids.

•Below the pond: Flue Gas Treatment Totals:

•Wet Total Solids: The sum of the wet FGD solids and the fly ash on a wet basis.

•Total Mercury: Mass flow rate of mercury present in the combined wet FGD solids and fly ash solids on a wet basis.
