The Air Separation Diagram result screen shows the major flows into and out of the chemical looping system's Air Separation Unit (ASU):
PC: GET RESULTS: CO2 Control: 1. Chemical Looping: Air Separation Diagram
Each result is described briefly below in flow order:
•Area 1: Atmospheric Air:
•Temperature In: Temperature of the atmospheric air entering the ASU.
•Air In: Mass flow rate of air entering the ASU, based on the atmospheric air temperature and atmospheric pressure.
•Air In: Volumetric flow rate of air entering the ASU, based on the atmospheric air temperature and atmospheric pressure.
•Area 2: Nitrogen:
•Nitrogen Out: Mass flow rate of the nitrogen exiting the ASU.
•Nitrogen Out: Volumetric flow rate of the nitrogen exiting the ASU.
•Area 3: Oxidant:
•Temperature Out: Temperature of the oxidant exiting the ASU.
•Oxidant Out: Mass flow rate of the oxidant exiting the ASU.
•Oxidant Out: Volumetric flow rate of the oxidant exiting the ASU.
•Area 4: Water:
•Water Out: This is the amount of water precipitated out of the ASU.
