Slip Stream Diagram

← Previous | Next →

The Slip Stream Diagram result screen is only shown when the slip stream treatment system is enabled. It is the same for all plant types:

PC: GET RESULTS: Water Systems: Wet Cooling Tower: Slip Stream Diagram

A slip or blowdown stream is removed from the wet cooling tower to reduce the concentration of impurities in the cooling water. The slipstream treatment system removes the impurities from the slip stream.

The following results are displayed:

•1: Water In: This is the amount of water entering the slip stream treatment system from the cooling tower.

•2: Water Out: This is the amount of water processed by the slip stream system. It is returned to the recirculating cooling water stream.

•3: Wastewater: This is the amount of wastewater leaving the slip stream treatment system. It is sent to the wastewater treatment facility.
