Work Samples


Take a look at some of the work samples that shop personnel have manufactured.


Mechanical Engineering Senior Design-Lunar Tool Carrier assembly, built & welded from 6061-T6 Aluminum & ToughPLA 3D printed components
Mechanical Engineering Senior Design - Lunar tool carrier assembly, built and welded from 6061-T6 aluminum and ToughPLA 3D printed components

Turning and polishing bronze pump seal riding surface for UW Central Energy Plant
Turning and polishing bronze pump seal riding surface for UW Central Energy Plant

Waterjet cutting 1inch thick mild steel brackets for welding fixture systems
Waterjet cutting one-inch thick mild steel brackets for welding fixture systems

12CF 3D printed ice coring drill bit & WJ machined steel support ring, tool steel cutting teeth
12CF 3D printed ice coring drill bit & WJ machined steel support ring, tool steel cutting teeth

Design build of stainless steel rock core sample holder, WJ cut, machined and ground
Design build of stainless steel rock core sample holder, WJ cut, machined and ground

Modeling, programming & CNC machining of spiral coil heat transfer assembly
Modeling, programming & CNC machining of spiral coil heat transfer assembly

Modeling, programming & CNC machining of spiral coil heat transfer assembly
Modeling, programming & CNC machining of spiral coil heat transfer assembly

Polycarbonate enclosure & painted steel frame for faculty’s lab surface grinder
Polycarbonate enclosure & painted steel frame for faculty’s lab surface grinder

TIG welding stainless steel pipe flanges for Chemical Engineering’s Coal Extraction Pilot Plant
TIG welding stainless steel pipe flanges for Chemical Engineering’s Coal Extraction Pilot Plant

Waterjet machined connector cutouts in black satin finish electrical cover panels
Waterjet machined connector cutouts in black satin finish electrical cover panels

Metal fan blower on table

Custom blower housing manufactured through sheet metal forming and high quality TIG welding.

Metal gear next to coin on table
Impeller used to drive an ice drill. Vanes required 4-axis machining.

Metal cart on floor
Stainless steel as cylinder cart.

Metal combustion chamber on dolly
Stainless steel combustion research chamber.

Circular metal piece
Large CNC-machined optical bench enclosure for Lidar system.

Metal pieces on table
Custom CNC machined spindles for SAE Baja.

Machining mount adapter plate-for 5-axis mini mill
Machining mount adapter plate-for 5-axis mini mill

Micro scale-Coil Winding fixture
Micro scale-Coil Winding fixture

C-Face type Motor Mount plate-Continuous Coal Extraction Pilot Plant project
C-Face type Motor Mount plate-Continuous Coal Extraction Pilot Plant project

Heavy structural tubing fixtures for Civil Engineering load frame testing
Heavy structural tubing fixtures for Civil Engineering load frame testing
