University of Wyoming Near Surface Geophysics (UWNSG)UWNSG Equipment:

Software

Seismic (Refraction, Reflection and Surface Wave):

Geometrics Geodes (10): 240 channel capability Click for More Information on Geodes	Geophones: 4.5Hz
Geophones:10Hz	Geophones: 40Hz
Geophones: Horizontal Phones	Sledge Hammers: 14 lb
Strike Plates: Lexan or Steel	Geophone Feet:
Geophone Cables: 5m takeout spacing with 10m ends Click for More Information on ProSeismic Cables	Spring Actuated Hammer (SAH): Truck mounted impact source
Geode Interconnect Cable: 100m	Geode Interconnect Cable: 25m
Borehole/Marine Hydrophone Arrays (2): 24 channel with 1m element spacing Click for More Information on Geometrics Hydrophones Click for More Information on ProSeismic Cables

DC Resistivity/Induced Polarization/Self-Potential:

Advanced Geosciences (AGI) SuperSting R8/IP/SP (4): 56 electrode capability (Total of 224 electrode capability thru 4 – 56 electrode switch boxes) WiFi Capabilities Click for More Information on the Wi-Fi Enabled SuperSting No Wifi Capabilities	Electrode Cables: 50m/5m/2m Click for More Information on Electrode Cables
SuperSting External Switchboxes: SSR8
Non-Polarizable Electrodes (60): Boron-Stealth Silver-Silver Chloride AGI Cu-Cu-SO4	56 Electrode Borehole/Marine Tow Cables (2): 1m electrode spacing
Advanced Geosciences (AGI) PowerSting: 10KW transmitter (2000V/5A) Click for More Information on the PowerSting 28 HP PowerSting nodes Click for More Information on the Transmitter Nodes	HP Interconnect Cables for the PowerSting (28): 100m
Portable Generator: 25KW for PowerSting	Multi-Phase Technologies (MPT) DAS-1: 64 electrode capability (Total of 320 electrode capability thru 4 additional 64 electrode MUX units) Click for More Information on the DAS-1

Ground-Penetrating Radar:

Mala ProEx with Shielded Antenna: 100MHz (1) 250MHz (2) 500MHz (2) 800MHz (2) Click for More Information on Mala Antennae	Sensors & Software Noggin with Shielded Antenna: 100MHz (1) 250MHz (1) 500MHz (1) Click for More Information on Noggin Antennae
Mala GPR Monitor: Screen	Mala ProEx Unit: GPR Control Unit
Mala ECU: Electronics Control Unit

Borehole Geophysical Logging:

Mount Sopris Instruments - Slimline MATRIX Borehole Geophysical Logging System: 500m winch Small Tripod Large Tripod

Mount Sopris Instruments - Slimline MATRIX Borehole Geophysical Logging System: QL-40 probes: 2-arm Caliper, Optical Televiewer, Acoustic Televiewer, Natural Gamma, Fluid Temperature/Conductivity, Spectral Gamma, Spinner Flowmeter, Heat Pulse Flowmeter, Electromagnetic/Magnetic Susceptibility, Full Waveform Sonic (3 receiver), Resistivity (normal 8", 16", 32", 64"), Induced Polarization/ Self-Potential, Fluid Sampler 2STA and 2SMA 40SPA and QL40FTC Q40SFM and HFP QL40CAL QL40ABI and QL40OBI QL40RES-TP QL40SGR

Javelin/Dart Borehole NMR Logging System: Javelin Surface Station Click for More Information on the Javelin NMR System

Javelin/Dart Logging Tools: Logging Instruments 1.75 OD Dart 1.75 OD 3.5 OD

Gravity:

Scintrex CG-5: Microgravimeter Click for More Information on the Autograv

Magnetics:

Geometrics G856 (2): Proton precession magnetometers (digital base and analog)

Geometrics G858G: Cesium vapor gradient magnetometer Click for More Information on the G-858G

Direct Push Sampling/Rotary Coring/HPT-EC Direct Imaging:

Geoprobe: 7822DT Click for More Information on the 7822DT Geoprobe

Geoprobe Accessories: 4.5" Augering (50ft) Click for More Information on Augering Tools 1.25" and 2.25" Dual Tube push sampling (100ft), 2.75" NQ coring (100ft), Hydraulic pressure test and electrical conductivity (HPT/EC) direct image testing (100ft)

Electromagnetics:

Dual EM-1S: Soil conductivity instrument Click for More Information on the 1S	Geophex GEM2: Multifrequency soil conductivity meter Click for More Information on the GEM-2
ABEM - Walk TEM Surface EM: 5m and 40m receiver loops, 100m current loop Click for More Information on the WalkTEM

Magnetic Resonance Sounding (NMR):

GMR by Vista Clara Converter 540V DC/DC converter Click for More Information on the GMR System	GMR by Vista Clara Tuning Unit: 16µF tuning unit Click for More Information on the GMR System
GMR by Vista Clara Transmitter: 4000V transmitter Click for more information on the GMR System	Cable Reels: 150m (12)

Natural and Controlled Source Magnetotellurics:

Geometrics Stratagem: EH-4 Click for More Information on the Stratagem

Sub-Bottom Profiling:

Knudsen PINGER: Portable shallow water CHIRP sub-bottom profiler Click for More Information on the PINGER

GPS:

Trimble R8: Base and RTK capability Click for More Information on the R8

GEOXH Handheld Receiver (3): RTK rover capability
